تفاصيل المنتج:
|
| هيكل المنتجات: | قابل للتوصيل | IIMP: | 25KA |
|---|---|---|---|
| مستوى الحماية: | اكتب 1+2 | وزن: | 1kgs |
| درجة حرارة التشغيل: | -40 درجة مئوية إلى 80 درجة مئوية | عرض منتج قطب واحد: | 36 ملم |
| مادة الضميمة: | البلاستيك الحراري UL94-V0 | الجهد المقنن: | 150 فولت/275 فولت/320 فولت/440 فولت |
| إبراز: | Type 1 surge protection device 150V,BR-25M surge protective device 440V,Type 1 SPD with warranty,BR-25M surge protective device 440V,Type 1 SPD with warranty |
||
Product characteristics:
| Specification | BR-25M 150 3+1 | BR-25M 275 3+1 | BR-25M 320 3+1 | |
| SPD classification according to EN61643-11 | Type 1 + 2 + 3 | Type 1 + 2 + 3 | Type 1 + 2 + 3 | |
| SPD classification according to IEC61643-11 | Class I + II + III | Class I + II + III | Class I + II + III | |
| Nominal operating voltage | Un | 120V/240V(50/60Hz) | 230V/400V(50/60Hz) | 250V/440V(50/60Hz) |
| Max. continuous operating a.c. voltage | Uc (L-N/N-PE) | 150V/255V(50/60Hz) | 275V/255V(50/60Hz) | 320V/255V(50/60Hz) |
| Lightning impulse current (10/350μs) | Iimp (L-N/N-PE) | 25kA/100kA | 25kA/100kA | 25kA/100kA |
| Total discharge current (10/350μs) | Itotal | 100kA | 100kA | 100kA |
| Nominal discharge current (8/20μs) | In (L-N/N-PE) | 25kA/100kA | 25kA/100kA | 25kA/100kA |
| Max. discharge current (8/20μs) | Imax (L-N/N-PE) | 120kA/200kA | 120kA/200kA | 120kA/200kA |
| Quantity of electric charge (L-N, N-PE) | Q | 12.5As, 50As | 12.5As, 50As | 12.5As, 50As |
| Specific energy (L-N, N-PE) | W/R | 156kJ/Ω, 2500kJ/Ω | 156kJ/Ω, 2500kJ/Ω | 156kJ/Ω, 2500kJ/Ω |
| Voltage protection level | Up (L-N/N-PE) | ≤0.8kV/≤1.5kV | ≤1.3kV/≤1.5kV | ≤1.3kV/≤1.5kV |
| Short-circuit current rating a.c. | Isccr (L-N/N-PE) | 25kA rms/100A rms | 25kA rms/100A rms | 25kA rms/100A rms |
| Max. backup fuse | 200A gG | 200A gG | 200A gG | |
| Temporary overvoltage TOV-withstand | UT(L-N) | 180V/5sec. | 335V/5sec. | 400V/5sec. |
| Temporary overvoltage TOV-safe failure | UT(L-N) | 230V/120min. | 440V/120min. | 520V/120min. |
| Temporary overvoltage TOV-withstand | UT(N-PE) | 1200V/200ms | 1200V/200ms | 1200V/200ms |
| Leakage current | Ipe | None | None | None |
| Response time | tA | ≤25ns/≤100ns | ≤25ns/≤100ns | ≤25ns/≤100ns |
| Operating temperature range | Tu | -40℃-80℃ | -40℃-80℃ | -40℃-80℃ |
| Operating state/fault indication | green/red | green/red | green/red | |
| Cross-section area (Min.) | 4mm² | 4mm² | 4mm² | |
| Cross-section area (Max.) | 35mm² | 35mm² | 35mm² | |
| For mounting on | 35mm Din rail | |||
| Enclosure material | Thermoplastic UL94-V0 | |||
| Degree of protection | IP20 | IP20 | IP20 | |
| Order Code | B17208 | B18163 | B17221 | |
| Order Code (With remote signaling) | B17209 | B18164 | B17222 | |
Features:
The surge arrestors BR-25M meet the Class I and Class II requirement class according to IEC 61643-11.
Labeled connections.
Electrical surge protector work by diverting the extra energy in the electrical surge away from the main circuit, usually to “earth”.
Surge protection devices (SPD) which is connected at the main distribution board is constantly monitoring the supply voltage.
Application:
These devices protect low-voltage consumer systems from overvoltage.
| Weight | 1kgs |
| Usage | Low Voltage |
| Application | Commercial/Industrial |
| OEM/ODM | YES |
| One pole Product Width | 36mm |
| Product Structure | Pluggable |
| Rated Voltage | 150V/275V/320V/440V |
| Enclosure Material | Thermolplastic UL94-V0 |
| Operating Temperature | -40°C To 80°C |
| Protection Level | Type 1+2 |
